Application：
Using in petrochemical industry, shipyard,etc. It could resist the super heated steam of maximum 230℃.
Temperature：-40℃ to +210℃(-40℉ to +410℉)
Tube：Black, smooth, Resistance to high temperature EPDM synthetic rubber.
Reinfrocement：High strength synthetic cord with 2 layers helix wire
Cover：Black, smooth(wrapped finish)synthetic EPDM rubber. High temperature, oil and weathering resistant.
Optional Request：High strength synthetic helix wire, Black cover, Negative pressure resistance.
I.D. I.D. O.D. W.P. W.P. B.P. B.P. Max. Length Max. Length inch nn nn bar psi bar psi m ft 3/8" 10 21 18 270 180 2700 120 400 1/2" 13 25 18 270 180 2700 120 400 1/2" 13 26 18 270 180 2700 120 400 5/8" 16 28 18 270 180 2700 120 400 3/4" 19 31 18 270 180 2700 120 400 3/4" 19 32 18 270 180 2700 120 400 3/4" 19 33 18 270 180 2700 120 400 1" 25 37 18 270 180 2700 120 400 1" 25 38 18 270 180 2700 120 400 1 1/4" 32 44.5 18 270 180 2700 120 400 1 1/4" 32 46.5 18 270 180 2700 120 400 1 1/2" 38 52 18 270 180 2700 120 400 1 1/2" 38 54 18 270 180 2700 120 400 2" 51 65 18 270 180 2700 120 400 2" 51 65.5 18 270 180 2700 120 400 2" 51 67 18 270 180 2700 120 400 2 1/2" 63.5 81.5 18 270 180 2700 120 400 3" 76 96.5 18 270 180 2700 120 400 3 1/2" 90 110 18 270 180 2700 60 200 4 1/4" 108 130 18 270 180 2700 60 200 1/2" 13 27.5LL 18 270 180 2700 120 400 3/4" 19 33.5LL 18 270 180 2700 120 400 1" 25 39.5LL 18 270 180 2700 120 400 1 1/4" 32 48LL 18 270 180 2700 120 400 1 1/2" 38 56LL 18 270 180 2700 120 400 2" 51 69LL 18 270 180 2700 120 400 2 1/2" 63.5 85.5LL 18 270 180 2700 120 400 3" 76 98LL 18 270 180 2700 60 200 3 1/2" 90 114LL 18 270 180 2700 60 200 4 1/4" 108 132LL 18 270 180 2700 60 200
Material:Good quality materials make our steam hose steady performance.
Production:Advanced technology and equipment to make the best quality rubber steam hose.
Laboratory:
Our factory has strong quality control team, we set up advanced laboratory.
Before the mass production, we test each batch of raw material.
After the production, we test each hose to guarantee a 100% qualification.
Each hose tested at 3 times of working pressure.
Packaging: After finishing the hose production, we will pack the hose.
In general, the packing will use woven bag and plastic film.
Special packing is available according to customers’ requirements.
Market & Exports: Our product has exported to over 30 countries,
including the United States, Britain, Brazil, Russia and so on.
Trade shows: we participate in overseas exhibitions every year.
