Applications
Designed for pressure transmission for auto, truck and trailer hydraulic pressure brake systems.
Truck and trailer manufacturers,aftermarket packagers and wholesalers use this hose.
It is certified to meet SAEJ1401 requirements.
Temperature range -40~+100°C
Construction
External layer:CR/EPDM
Reinforcement :PET
Middle layer :NBR
Reinforcement :PET
Internal layer:EPDM
BRAKE HOSE SAE J1401 Item Code I.D O.D Wall Thickness Wall Diff Expansion Max. ml/m Min.Brust Pressure mm mm mm mm 6.9MPa 10.3MPa MPa TPH-01 3.2 10.5±0.2 3.65 ≤0.25 <1.08 <1.38 >80 TPH-02 4.8 13±0.3 4.35 ≤0.3 <1.81 <2.36 >60 TPH-03 6.3 15±0.3 3.75 ≤0.3 <2.69 <3.84 >50 TPH-04 4 8 50 150 35 47
